Connector Material Grading Chart
Not all flex connector materials perform the same. Use this grading chart to compare abrasion resistance, tear strength, weather durability, temperature range, and more across all nine connector materials we offer — from corrugated boots to cut-to-length tubing. Each grade reflects real-world performance for vibratory screening applications.
A = ExcellentB = GoodC = FairD = PoorF = Not Functional
 |
Fixed Length Corrugated Connector Materials | Cut To Length Materials | |||||||
|---|---|---|---|---|---|---|---|---|---|
 |
 |
 |
 |
 |
 |
||||
| Natural Rubber | Neoprene Rubber | EPDM Rubber | Silicone | Pure Gum Rubber | Clear Flex Polyurethane | Rubber Coated Nylon | Silicone | Wire-Infused Polyurethane | |
| Abrasion Resistance | A | B | C | C | A | A | B | C | A |
| Tear Strength | A | C | C | D | A | A | B | C | A |
| Weather Durability | C | B | A | A | C | A | C | A | A |
| Ease of Cleaning | D | D | D | D | B | A | B | B | C |
| Temperature Range (°F) | 0 to 120 | 0 to 150 | -40 to 250 | -60 to 550 | 0 to 120 | 20 to 250 | -31 to 250 | -80 to 450 | -22 to 195 |
| Customizability | F | F | F | F | B | A | A | F | F |
| Cost per Foot | A | B | C | D | B | A | C | D | D |
| Shipping Cost Efficiency | C | C | C | C | B | A | A | B | C |
Need Help Choosing the Right Connector Material?
Our team can recommend the best material for your specific vibratory screening application, temperature requirements, and budget.
